jhemcu flight controller ghf420aio f4 osd built-in 20a 35a blheli_s 2-6s 4in1 esc for cinewhoop racing toothpick drones rc fpv
Specification:
Brand: JHEMCU
Model: GHF420AIO
Item Name: f4 osd embedded flight controller 20a/35a 4in1 esc
Size: 30x37.5mm
Mounting hole: 20x20mm
Weight: 7.9g
CPU: STM32F405RGT6
Mpu: mpu6000 (spi)
Firmware: Betaflight BETAFLIGHTF4.HEX
Built in betaflight osd (at7456e)
Bec output (two): 9v/2a, 5v2.5a
Usart: uart1, uart2, uart3, uart6
Receiver; sbus, bus, dsm2, dsmx, ppm, tbs (uart6)
Blackbox: 8MB
Built-in current sensor
Support WS2812 LEVOU
Buzzer:5v bz-
Input voltage: 2-6s lipo
Current Esc: 20a/35a
Firmware: BLHELI_S G-H-30.HEX
-Support pwm, oneshot42, oneshot125, multishot, dshot150 and dshot300, dshot600
