Caddx 5.8GHz Vista HD Digital System FPV Transmitter VTX 150 Degree Camera 1080P FPV Goggles For Small HD Drones Whoop Airplane
Item name:Caddx 5.8GHz Vista HD Digital System FPV Transmitter VTX 150 Degree Camera 1080P FPV Goggles For Small HD Drones Whoop Airplane
The Vista HD System is designed for small drones and whoop drones. It can work with DJI FPV Camera,DJI FPV Goggles and DJI FPV Remote Controller. Compatible with two sizes,20*20mm/25.5*25.5mm, compatible with toothpick drones.



The Vista HD System is designed for small drones and whoop drones. It can work with DJI FPV Camera,DJI FPV Goggles and DJI FPV Remote Controller. Compatible with two sizes,20*20mm/25.5*25.5mm, compatible with toothpick drones.
Specifications:
Brand Name: Caddx
Item Name: Vista Kit
Operating Frequency: 5.725-5.850GHz
Transmitter Power(EIRP): FCC/SRRC/MIC: <30dBm, CE: <14dBm
Min. Latency (end-to-end): Low Latency Mode(720p 120fps): 21-28ms, High Quality Mode(720p 60fps): 30-40ms
Max. Transmission Distance: FCC/SRRC: 4km, CE: 0.7km
I/O Interface: USB-C,IPEX,3-in-1 Port,microSD card slot
Supported Flight Control System: F3,F4,F7
Operating Temperature Range: 32° to 104° F (0℃ ~40℃)
Input Power: 7.4-26.4V
DJI Camera Specifications:
Sensor: 1/3.2'' CMOS
Effective Pixels: 4M
Lens: 2.1mm,f/2.1
Shutter: Rolling shutter
ISO: 100-25600
FOV: 150° (D);122° (H);93° (V)
Weight:
Vista Kit(camera included): 29g
Antenna: 3.5g
Dimensions:
Vista Kit: 30x29x13mm
Camera: 27.4x21.1x20.1mm
Coaxial Cable:80mm
Features:
- Stable and clear HD video.
- Single antenna,max range is up to 4km.
- Allow up to 8 drones to fly simultaneously.
- Embedded remote controller receiver.
- 28ms ultra low latency,high definition digital image transmission.
